Brief Introduction:
Kejia Electric trolley furnace consists of high quality alumina fiber brick and MoSi2 rods heating elements, the internal chamber heated from four sides, furnace bottom together with furnace door can be pushed in and out electrically. It is an ideal tool for materials annealing and sintering in your research laboratory.
The main features are as below:
1. High uniform temperature.
2. Temperature Control Accuracy:±1℃
3.Easy to operate.
4.Over temperature protection and alarm.
5.Furnace door with bottom part can be pushed in and out manualy.
Technical Parameter:
Kejia Electric trolley furnace consists of high quality alumina fiber brick and MoSi2 rods heating elements, the internal chamber heated from four sides, furnace bottom together with furnace door can be pushed in and out electrically. It is an ideal tool for materials annealing and sintering in your research laboratory.
The main features are as below:
1. High uniform temperature.
2. Temperature Control Accuracy:±1℃
3.Easy to operate.
4.Over temperature protection and alarm.
5.Furnace door with bottom part can be pushed in and out manualy.
Technical Parameter:
| 1 | Chamber Structure | Electric trailer type |
| 2 | Display | LED |
| 3 | Furnace body structure | Double layer structure with cooling fan |
| 4 | Furnace shell material | Carbon steel |
| 5 | Max. Temperature | 1700℃ |
| 6 | Continuous working Temperature | ≤1600℃ |
| 7 | Heating Rate | 20℃/min (Suggest 0~10℃/min) |
| 8 | Accuracy | ±1℃ |
| 9 | Inside Chamber Size | 600x600x600mm |
| 10 | Heating Element | High purity MoSi2 rods |
| 11 | Heating method | Heating from four sides |
| 12 | Insulation material | High purity alumina fiber |
| 13 | Thermocouple | B Type |
| 14 | Max. Power | 60KW(according to design) |
| 15 | Working Voltage | 380V, three phase, 60HZ |
| 16 | Temperature Controller | YOKOGAWA brand Model: UP35A-001-11-00 Separate control cabinet |
| 17 | Heating method | Heating from right, left and back side |
| 18 | Warranty | One year limited warranty (Consumable parts such as heating elements are not covered by the warranty) |
